14 19-inch module for SysLink system connector
© Festo Didactic 759614
45
14.3 Technical data
Electrical/Mechanical
Operating voltage 24 V DC ± 3%
Digital inputs/outputs
Input voltage
Output current
0 V to operating voltage
Module: max. 0.5 A per output
PLC: see PLC manual
Analog inputs/outputs
Input/output voltage
Input impedance
Output current
0 to 10 V DC and ± 10 V DC respectively
See PLC manual
Module: max. 0.5 A per output
PLC: see PLC manual
Connection 4 mm safety sockets
Front-plate width 9 HP
Subject to change
14.4 Contact allocation table
14.4.1 Analogue inputs/outputs
Pin SV14 SV10 SV13 SV11 SV12 X2
1 UA1 GNDE 0V GNDA IE3 UA1
2 IA2 IE3 IA2 IA2 GNDE UA2
3 UA2 GNDE 0V GNDA IE3 GNDA
4 IA1 UE3 GNDA UA2 UE3 IE2
5 GNDA GNDE 0V GNDA IE3 IE1
6 — GNDE UA2 IA1 IE2 GNDE
7 IE2 GNDE 0V GNDA IE3 UE2
8 IE4 IE2 IA1 UA1 GNDE UE1
9 IE1 L3+ UE4 UE4 L3+ IA2
10 IE3 UE2 GNDA — UE2 IA1
11 GNDE L3+ UE4 UE4 L3+ —
12 UE4 GNDE UA1 — IE1 IE4
13 UE2 L3+ UE4 UE4 L3+ IE3
14 UE3 IE1 IE4 GNDE GNDE UE4
15 UE1 L3+ UE4 UE4 L3+ UE3
16 — UE1 GNDE IE4 UE1 —
