8 19-inch module 8DOUT
28 © Festo Didactic 759614
8.2 Commissioning
1. Connect the inputs/outputs to the PLC using a flat cable:
– SV2: Siemens S7 (16-pin)
– SV1: Other controller types (10-pin)
2. If using modules in parallel, these can be connected via the free insulation-displacement connector SV1
or SV2 using flat cables.
3. Connect the 24 V power supply by means of the 3-pin connector SL1 or SL2.
4. The jumper JP1 is used to define whether the output module is supplied directly via 24 V or via 24 V NA.
24 V NA is switched off in the event of an EMERGENCY-STOP.
– Jumper between pins 1 and 2: supply via 24 V.
– Jumper between pins 2 and 3: supply via 24 V NA.
5. Screw the 19-inch module into the frame.
8.3 Technical data
Electrical/Mechanical
Operating voltage 24 V DC
Output current
Module: max. 0.5 A per output
PLC: see PLC manual
Connection 4 mm safety sockets
Front-plate width 6 HP
Subject to change
8.4 Contact allocation table
Pin SV1 SV2 Pin SV1 SV2
1 L1+ 0V 9 Q7 L1+
2 Q0 Q7 10 0V Q3
3 Q1 0V 11 — L1+
4 Q2 Q6 12 — Q2
5 Q3 0V 13 — L1+
6 Q4 Q4 14 — Q1
7 Q5 0V 15 — L1+
8 Q6 Q4 16 — Q0
