10 19-inch module 4AIN/2AOUT
32 © Festo Didactic 759614
10.2 Commissioning
1. Connect the inputs/outputs to the PLC using a flat cable:
– SV2/SV5: Siemens S7 integrated analog module with 40-pin plug (2 x 16-pin)
– SV1/SV6: Other controller types (16-pin)
2. If using modules in parallel, these can be connected via the free insulation-displacement connector SV1
or SV6 using flat cables.
3. Connect the 24 V power supply by means of the 3-pin connector SL1 or SL2.
4. Use the jumper JP2 to define whether the output module is supplied directly via 24 V or via 24 V NA.
24 V NA is switched off in the event of an EMERGENCY-STOP.
– Jumper between pins 1 and 2: supply via 24 V.
– Jumper between pins 2 and 3: supply via 24 V NA.
5. Screw the 19-inch module into the frame.
10.3 Technical data
Electrical/Mechanical
Operating voltage 24 V DC ± 3%
Input/output voltage 0 – 10 V DC and ± 10 V DC respectively
Input impedance See PLC manual
Output current
Module: max. 0.5 A per output
PLC: see PLC manual
Connection 4 mm safety sockets
Front-plate width 12 HP
Subject to change
10.4 Contact allocation table
Pin SV1 SV2 SV3 SV4 SV5 SV6
1 UA1 0V IE3 0V 0V UA1
2 IA2 IE3 0V IA2 IA2 IA2
3 UA2 0V IE3 0V 0V UA2
4 IA1 UE3 UE3 0V UA2 IA1
5 0V 0V IE3 0V 0V 0V
6 — 0V IE2 UA2 IA1 —
7 IE2 0V IE3 0V 0V IE2
8 IE4 IE2 0V IA1 UA1 IE4
9 IE1 L1 L1 UE4 UE4 IE1
10 IE3 UE2 UE2 0V — IE3
11 0V L1 L1 UE4 UE4 0V
12 UE4 0V IE1 UA1 — UE4
13 UE2 L1 L1 UE4 UE4 UE2
14 UE3 IE1 0V IE4 0V UE3
15 UE1 L1 L1 UE4 UE4 UE1
16 — UE1 UE1 0V IE4 —
