11 19-inch module 4AIN/2AOUT, without simulation
34 © Festo Didactic 759614
11.2 Commissioning
1. Connect the outputs to the PLC/LOGO! with 8 single wires.
2. Screw the 19" module into the rack.
11.3 Technical data
Electrical/mechanical specifications
Operating voltage 24 V DC ±3%
Input/output voltage 0 to 10 V DC or ±10 V DC
Input impedance See PLC manual
Output current Module: max. 4.0 A per output
PLC: see PLC manual
Connection 4 mm safety sockets
Front panel width 6 standard width units
Subject to change
11.4 Pin allocation table
Pin SV1 SV2 SV3 SV4 SV5 SV6
1 UA1 0 V IE3 0 V 0 V UA1
2 IA2 IE3 0 V IA2 IA2 IA2
3 UA2 0 V IE3 0 V 0 V UA2
4 IA1 UE3 UE3 0 V UA2 IA1
5 0 V 0 V IE3 0 V 0 V 0 V
6 — 0 V IE2 UA2 IA1 —
7 IE2 0 V IE3 0 V 0 V IE2
8 IE4 IE2 0 V IA1 UA1 IE4
9 IE1 L1 L1 UE4 UE4 IE1
10 IE3 UE2 UE2 0 V — IE3
11 0 V L1 L1 UE4 UE4 0 V
12 UE4 0 V IE1 UA1 — UE4
13 UE2 L1 L1 UE4 UE4 UE2
14 UE3 IE1 0 V IE4 0 V UE3
15 UE1 L1 L1 UE4 UE4 UE1
16 — UE1 UE1 0 V IE4 —
