12 19-inch module for word processing
SV1, SV2: 10-pin outputs (high/low byte)
SV3, SV4: 10-pin inputs (high/low byte)
SV5, SV6: 16-pin outputs (high/low byte)
SV7, SV8: 16-pin inputs (high/low byte)
JP1, JP2: Supply via 24 V or 24 V NA
SL1, SL2: Connections for 24 V DC supply voltage
Caution
This module is designed for direct connection to a PLC and must not be connected in parallel with
other modules. This could damage the module outputs.
