5. Maintenance and conversion
5-8
Festo P .BE-MPA-EN en 1108e
1 Fastening screws
of the valve or
blanking plate
2 V alve or blanking
plate
3 Cord seal
4 Electronics
module
5 Sub-base
1
2
3
4
5
Fig. 5/2: Mounting valve or blanking plate (MPA1)
2
1
2
3
4
5
1 Fasteni ng screws of the component
2 V alve or blanking plate
3 Cord seal
4 Sub-base
5 Electronics module
Fig. 5/3: Mounting valves or blanking plates (MPA2)
