5. Maintenance and conversion
5-19
Festo P.BE-MPA-EN en 1108e
Mounting Proceed as follows:
1. Make sure the seals are not damaged. Replace the seals if
they are damaged.
2. Place the seal onto the guide pin of the sub-base or
supply plate.
1 Guide pins
2 Seal (optional
separating seal
for pressure zone
separation)
2
1
1
Fig. 5/7: Connecting plate mounting
