5. Maintenance and conversion
5-24
Festo P .BE-MPA-EN en 1108e
1 End piece
Type MPA
1
Fig. 5/12: Mounting the end piece into the last interlinking board
3. Mount the sub-base to the neighbouring components
(see section 5.3.6).
4. Mount the electronics module into the sub-base
(see section 5.3.5).
5. Mount all the valves and blanking plates again onto the
sub-base (see section 5.3.3).
