A. Technical appendix
A-3
Festo P.BE-MPA-EN en 1108e
A.1 Technical data
Note
The valves can be used at temperatures down to -5 °C.
In order to prevent the condensate and the humidity from
freezing, we recommend that you install a dryer with which
condensate and humidity can be removed.
General
Permitted temperature range
– Long-term storage
–Operation
–Medium
- 20 ... + 40 °C
- 5 ... + 50 °C
- 5 ... + 50 °C
Protection class as per EN 60 529 IP65 (with cable from Festo
accessories)
Relative humidity 90 % at 40 °C
Corrosion protection KBK1 (as per FN940070)
Mounting position as desired, with H-rail mounting only
horizontal
Tightening torque (M
A
)
– Electronics modules o n sub-bases
– Proportional pressure regulator on sub-ba se
– Exhaust plates
– Flat plate silencer
– Fastening of sub-bases, electric and pneumatic supply
plates (linking)
– Board in multiple connector plate
– Multi-pin hood on multiple c onnector plate
– Support bracket on sub-bases or supply plates
– Retaining screw for H-rail clamping
0.4 Nm (± 20 %)
2.0Nm(±20%)
0.65 Nm (± 10 %)
1.0Nm(±10%)
1.8Nm(±10%)
1.0Nm(±10%)
0.65 Nm (± 10 %)
1.8Nm(±10%)
1.30 Nm
MPA1 MPA2
– Components on sub-bases (valve, blanking plate or
pressure regulator)
0.25 Nm (± 10 %) 0.65 Nm (± 10 %)
