B. Supplementary component summary
B-13
Festo P.BE-MPA-EN en 1108e
B.2 Separating the MPA-S valve terminal from the CPX terminal
TheMPA-SvalveterminalisconnectedtotheCPXterminalby
means of a pneumatic interface (see following diagram).
1 CPX terminal
2 Pneumatic
interface
3 MPA-S Valve
Terminal
123
Fig. B/1: Pneumatic interface
Dismounting Proceed as follows:
1. Loosen the electrical and pneumatic connections and then
removetheMPA-Svalveterminalfromitsfastening
surface (see Chapter 5, “Dismantling the MPA-S valve
terminal”).
2. L o osen the fastening screws between the pneumatic
interface and the M PA sub-base in the sequence 32
1 (see Fig. B/2).
3. Then loosen the retaining screws.
