1. Summary of components
1-10
Festo P .BE-MPA-EN en 1108e
1
2
3
1
4
5
5
1
Exhaustplate(3/5)orflatplate
silencer
2 Electronic module with LEDs
3 V alve or blanking plate
4 V ertical pressure isolating plate
5 Pressure regulator plate
Fig. 1/7: Components of the MPA-S valve terminal with CPX terminal or CPI module,
2
nd
level
