1. Summary of components
1-11
Festo P.BE-MPA-EN en 1108e
The MPA-S valve terminal with electric multi-pin or AS
interface consists of the following pneumatic components:
25 3
4
1
4
1 Right end plate
2 Pneumatic supply plate
3 Inscription label with support
4 Sub-base with work connections and
electric linking
5 Seal (optionally isolating seal for
forming pressure zones)
Fig. 1/8: Components of the MPA-S valve terminal with electric multi-pin or AS
interface 1
st
level
