1. Summary of components
1-12
Festo P .BE-MPA-EN en 1108e
1
4
3
2
2 1
5
4
1
Exhaustplate(3/5)orflatplate
silencer
2 V alve or blanking plates
3 V ertical pressure isolating plate
4 Pressure regulator plate
5 Electronic module with LEDs
Fig. 1/9: Components of the MPA-S valve terminal with electric multi-pin or AS
interface 2
nd
level
