1. Summary of components
1-26
Festo P .BE-MPA-EN en 1108e
Pressure regulator plates
The pressure regulator plates of the vertical stacking are
marked on the MPA-S valve terminal with the ident. code.
This is marked on the side of the pressure regulator plate.
You can identify the pressure regulator plate using the
following table.
Ident.
code
Vertical stacking components
PF P pressure regulator plate for port (1), control range 0.5 ... 6 ba r
PH B pressure regulator plate fo r port (2), control range 2 ... 6 bar
PG A pressure regulator plate f or port (4), control range 2 ... 6 b ar
PN Reversible B pressure regulator plate for port (2), control range 0.5 ... 6 b ar
PM Reversible A pressure regulator plate for port (4), control range 0.5 ... 6 bar
PA P pressure regulator plate for port (1), control range 0.5 ... 10 bar
PC B pressure regulator plate for port (2), control range 2 ... 10 bar
PB A pressure regulator plate for port (4) , control range 2 ... 10 bar
PL Reversible B pressure regulator plate for port (2), control range 0.5 ... 10 ba r
PK Reversible A pressure regulator plate for port (4), control range 0.5 ... 10 bar
Tab. 1/10: Identification of the pressure regulator plates in the type code
The circuit symbol of the pressure regulating valve is
provided in Appendix B, Tab. B/5.
Instructions on the installation of the pressure regulator
plates are provided in the assembly instructions
VMPA...-B8-R...C2-C...
