1. Summary of components
1-36
Festo P .BE-MPA-EN en 1108e
Y ou will find the following electric connecting elements on the
multi-pin plug connection of the MPA-S valve terminal:
1 Multi-pin plug
cover with cable
2 Connection for
functional earth
3 Sub-D connection
1
2
3
Fig. 1/16: Electric connecting elements of MPA-S valve terminal with multi-pin plug
connection
Information on the electronics module of the MP A-S valve
terminal can be found in the MPA-... electronics descriptions.
