Sorting Station Inline
20 © Festo Didactic 8129444
7 Technical data
7.1 General data
Parameter Value
Operating pressure 600 kPa (6 bar)
Operating voltage 24 V DC, 4 A
5 V DC, 3 A (Raspberry Pi)
Digital inputs/outputs
Inputs: 7
Outputs: 4
Max. 24 V DC
Max. 2 A per output
Max. 4 A total
Electrical connection 2x 24-pin IEEE-488 socket (SysLink)
Pneumatic connection Plastic tubing with 6 mm outside diameter
Compressed air consumption at 600 kPa (continuous cycle) 3 l/min
Dimensions 350 mm x 700 mm x 353 mm (without carriage)
350 mm x 700 mm x 1104 mm (incl. carriage)
Subject to change
