7.2 Pin allocation table
Digital
Function SysLink Color Designation
I0 13 Gray-pink Workpiece at start of conveyor
I1 14 Red-blue Deflector 1 advanced
I2 15 White-green Deflector 2 advanced
I3 16 Brown-green Slide not full/Workpiece not at end of conveyor
I4 17 White-green Workpiece detected
I5 18 Brown-yellow Workpiece not black
I6 19 White-yellow Workpiece metallic
I7 20 Grey-brown
Q0 1 White Conveyor belt forward
Q1 2 Brown Conveyor belt reverse
Q2 3 Green Advance deflector 1
Q3 4 Yellow Advance deflector 2
Q4 5 Gray
Q5 6 Pink
Q6 7 Blue
Q7 8 Red
24 V A 9+10 Black 24 V supply for outputs
24 V B 21+22 White-pink 24 V supply for inputs
GND A 11 Brown-pink 0 V power supply for outputs
GND A 12 Purple 0 V power supply for outputs
GND B 23+24 White-blue 0 V power supply for inputs
•
Cable jumpers are connected from emergency off to bit 1.5 on all
preferred PLC versions.
•
You can find electric circuit diagrams for the Sorting Station Inline
at the "Festo Didactic Info Portal". (www.ip.festo-didactic.com)
