Sorting Station Inline
© Festo Didactic 8129444
27
Red workpiece detected, deposited on slide 1
4. Advance deflector 1
5. Workpiece ejected
6. Retract deflector 1
7. Conveyor motor off
Metallic workpiece detected, deposited on slide 2
4. Advance deflector 2
5. Workpiece ejected
6. Retract deflector 2
•
The sequence can be interrupted by pressing the EMERGENCY STOP button at any
time or by pressing the STOP button after the cycle.
•
The following applies when several stations are combined:
The individual stations are aligned in the reverse order to the flow of materials.
