Basic user manual
Finapres Nova
Version date: 04 April 2016
25
4 Finapres Nova description
4.1 Description of the Finapres Nova
Figure 4-1: The Finapres Nova
4.2 Connections and controls
On the front, back and on the right side of the Finapres Nova several connections
and controls are positioned.
Controls on the front
On the front of the touch screen you will find the touch ON/OFF touch button:
Figure 4-2: ON/OFF touch button
