A2
Basic user manual
Finapres Nova
Version date: 04 April 2016
85
Appendix 2 Technical specifications
In this annex the technical specifications of the Finapres Nova are described.
A2.1 Characteristics
Item
Value
Product category
Finapres Nova finger blood pressure measuring
device, with optional hardware modules and software
applications.
Product type
Finapres Nova
Measurement method
Arterial volume-clamp method of J. Peñáz and the
Physiocal criteria of K.H. Wesseling
Cuff pressure
Max. 350 mmHg
Pressure measurement
accuracy
1% of full scale (max. 3 mmHg)
Clinical Accuracy
Meets accuracy requirements of AAMI/ANSI/ISO
81060-2:2009 and EN1060-4:2004 only if a
calibration with the optional Upper Arm Calibration
module has been done.
Rate accuracy
(Rate [bpm] / 60) %
Interbeat interval
accuracy
Max 10 ms (non-accumulating)
A2.2 Finger cuffs
A2.2.1 Protective measures for finger cuff
Cuff pressures on the finger up to 350 mmHg are practically painless and do no
harm unless applied for long periods. Electrical circuits of the Finapres Nova do
not touch the skin, and are not in contact with body fluids. The following
measures are taken for the safety and comfort of the patient monitored and the
convenience of the operator.
A2.2.2 Electrical
 Low cuff LED current (<30 mA), voltage (<1.8 V) and power dissipation
(<50mW) prevent undue heating or skin irritation, or electrical hazard.
 An electrical short circuit in the cuff or the instrument depressurizes the cuff
within 1 second.
 An interrupted Frontend cable or cuff cable depressurizes the cuff within 1
second.
 All analog signal outputs are fully short circuit proof.
