Version date: 04 April 2016
1. Ensure the main switch on the
back of the Finapres Nova is set to
“0”.
2. Disconnect the power cord from
the mains outlet and the unit.
5.4 Measuring
5.4.1 Connecting the patient
Before the measurement is started, the finger cuff(s) and Frontend Unit must be
connected to the patient (see Appendix 3 - ’Connecting the patient’, page 93)
Ensure that the finger cuff is properly applied to the patient prior to
starting a measurement. If a measurement is started without a finger in
the finger cuff, the finger cuff may be damaged.
5.4.2 Connecting the Frontend Unit
To connect the Frontend Unit to the Finapres Nova:
Push the plug of the Frontend Unit
into the socket on the right side of
the Finapres Nova marked with
“FRONT END”.
Be careful when connecting the Frontend Unit!
The pins of the plug are vulnerable.
