Abbreviation
Name
description
min
max
unit
Interval
derived from BP
signal
height
Height
Difference between
the two sensors on
the HCU
-250
250
[mmHg]
PhysioCalActive
PhysioCal
active detected
indicates detection
that physioCal
calibration algorithm
is active (only for
finger-pressure)
0
1
[bool]
noBeatDetected
No beat
detected
indicates no beats
can be detected
0
1
[bool]
A2.4 Technical description
A2.4.1 Connectivity
USB port:
The USB ports should only be used to connect a key board, mouse or USB stick.
The USB ports are powered, use only devices capable of being connected to such
a powered USB port.
When a USB drive has caching enabled and has been removed improperly
from a computer/device it may no longer be recognized by the Finapres
NOVA. Please ensure that the used USB storage device has caching turned
off (in Windows  File Explorer  right mouse click on USB drive 
properties  hardware tab  properties  (change settings)  Policies 
disable Write caching policy).
Repairing the drive in Windows will solve the issue.
RS232:
Only to be used for data transfer according to the DatexOhmedaRS232 protocol.
For more information about the RS232 protocol, please contact Finapres Medical
Systems B.V. at support@finapres.com.
LAN:
Only to be used for data transfer according to standard Ethernet protocols.
A2.4.2 Mechanical
Unit:
Outer dimensions [mm]:
Console weight [kg]:
Main unit
333 x 277 x 260
5
Frontend Unit
65 x 50 x 30
0.75
