Basic user manual
Finapres Nova
Version date: 04 April 2016
35
1. Unlatch the plug by pulling the ribbed
part a few millimeter backwards
2. Pull the plug of the Frontend Unit out of
the socket.
When disconnecting, pull on the plug itself, not on the cable.
5.5 Reviewing a measurement
In this chapter the most common actions when reviewing a measurement are
explained. For more details about the functionality available in the “REVIEW
MEASUREMENTS” screen see Appendix A1.4.1.
After a measurement is stopped, the data of that measurement is shown in the
“REVIEW MEASUREMENTS” screen automatically. Alternatively, measurements
can be reviewed via “REVIEW MEASUREMENT” in the “MAIN MENU”.
1. Press the
“REVIEW
MEASUREMENT”
button.
 A file selection
screen appears.
