Version date: 04 April 2016
Figure A3-3: Connecting the finger cuffs to the Frontend Unit
7. Repeat step1 to 6 for a second finger, when finger switching measurement
mode has been selected.
Make sure to connect a finger cuff to the air and electrical connections
that are positioned above each other on the Frontend Unit.
A3.2 Connecting the height correction unit
1. Fix the reference ending of the height
correction unit to the patient's arm at
heart level near the body.
2. Connect to height correction unit
connector to the connector on the
Frontend Unit.
