TOTALPAC2 Page 1 of 12
TOTALPAC2 Integrated Fire Protection Systems
Mechanical Section - Deluge System
FM-086G-0-24D
1- Installation, Operations & instructions
See Trim Schematic at the end of the current Section
1.1 Installation
1. Install the TOTALPAC2 unit and connect the system
according to instruction manual and technical data
supplied.
Note: The drain collector shall be connected to an open
drain. Do not restrict or reduce drain piping.
2. Install the automatic sprinkler piping, releasing piping
detection and signaling circuits (if applicable) in
accordance with applicable standards.
3. Conform to local municipal or other codes regarding
installations of fire protection systems.
4. Perform preliminary inspection outlined in paragraph 1.2
prior to putting system in service.
5. Put the system into operation Place the system in service
as outlined in paragraph 1.3.
6. Perform the annual inspection sequence and test each
detector and alarm unit.
7. If the system does not operate as it should, make the
necessary corrections according to manuals issued or
consult your distributor or FireFlex Systems Inc.
8. Make sure that building owner or a delegated
representative has received instructions regarding the
operation of the system.
T
OTALPAC2 Units must be installed in an area not subject
to freezing temperatures or physical damage.
1.2 Preliminary inspection before placing the
system in service
1. Open door to mechanical section. Main Water Supply
Control Valve (D1) should be CLOSED. Priming
valve (B1) must be CLOSED. Air supply if applicable
must be CLOSED (see AIR SUPPLY SECTION). Flow
Test Valve (B6) and main drain valve (D3) must be
CLOSED. Alarm test valve (B5) must be CLOSED. All
gauges (B11, B12 and E3) should show 0 psi pressure.
2. Connect all detection and alarm audible devices
according to electrical schematics (see TBA field wiring
diagram in PROGRAMMING SECTION).
3. If applicable, connect the AC power for the control
panel (L1) on a separate breaker in the electric
distribution panel (see TBB field wiring diagram in
PROGRAMMING SECTION).
Note: Do not use these circuit breakers for other parallel
applications. If necessary, equip each circuit breaker with
a security seal in order to avoid accidental closing.
4. After the Deluge Valve is set, operation of the Deluge
valve requires the release of priming water from the
priming chamber. This may be by automatic or manual
operation of one of the release systems described
above. For specific trim arrangement, refer to the
MECHANICAL TRIM DESCRIPTION.
Note: Electric Release: Solenoid valves, system control
panels and electrical detectors must be compatible.
Consult the CONTROLS SECTION for compatibility charts.
