TOTALPAC2 Integrated Fire Protection System
Control Section
FM-086G-0-29C
1- Control Section with Control Panel
1.1 Product Description
The Control Panel Section of the Self-Contained
T
OTALPAC2 unit is an add-on cabinet that is installed on
the top of the trim enclosure at the factory. This cabinet is
fabricated of Gauge 14 steel, painted fire red with baked
powder paint making it rustproof, the same finish as the
Trim Enclosure.
The Control Panel Section is provided with a locked
stainless steel door on the front giving access to the basic
controls of the Control Panel. Once opened, the cabinet
door gives access to the panel's Terminal Strip (refer to
FIELD WIRING DIAGRAM for additional details), the
control panel main board, emergency batteries and other
related equipment. Refer to Figures 1 and 2 for additional
details.
1.2 Self-contained T
OTALPAC2 Unit (with Viking VFR-400
Control Panel)
The model VFR-400 is a listed and approved,
microprocessor based fire control/releasing panel. It is
primarily designed for use as a releasing panel for pre-
action, Surefire
®, Firecycle® III, and deluge, water based
extinguishing systems. The panel is available for use with
either 120VAC-60Hz or 220VAC-50Hz power supplies.
The battery compartment can hold two 12 volt batteries
which are charged by an internal battery charger.
Batteries are available to provide up to 90 hours of
backup power during AC power failure.
The VFR-400 panel can be used with a wide range of
compatible initiating devices such as pull stations, heat
detectors (including linear heat detectors), photo-electric
and ionization smoke detectors.
Pre-configured programs allow field programming for one
of twelve possible input/output combinations that are
available and listed for use with the T
OTALPAC2 System.
In fire conditions when an initiating device circuit (or
predetermined combination of circuits) is energized, the
panel activates the release and signaling circuits
according to the 'Program' setting.
On the panel's display board, the appropriate Alarm,
Trouble and Supervisory LED's will flash until the event
has been acknowledged. A message will be displayed on
the LCD as well.
WARNING ! For more information and technical data,
please see the VIKING VFR-400 INSTALLATION,
OPERATION AND INSTRUCTION MANUAL provided
with the TOTALPAC2 Unit.
1.3 VFR-400 Visual Indicators:
Red LED’s:
-Initiating Device Circuits Active (4),
-Notification/Release Circuits Active (4)
-Common Alarm (1)
Green LED:
-AC Power
Yellow LED’s:
Initiating Device Circuits Troubles (4)
-Output Circuits Troubles (4)
-Supervisory Initiating Zone (4)
-Supervisory Bell Output Active (4)
-Supervisory Zone,
-Supervisory 1,
Supervisory 2,
-Power Trouble
-Supervisory
-Trouble
-System Trouble
-Ground Fault
-Discharging/Discharged
-Alarm Silenced
1.4 Control Switches:
SCROLL UP / BUZZER SILENCE:
Acknowledge troubles and supervisory.
Once all events in trouble or supervisory state have been
viewed, the panel buzzer and appropriate output will
silence. The applicable TROUBLE or SUPERVISORY
LED will change from flashing to steady.
A Second trouble or supervisory will resound the panel
buzzer.
Trouble conditions are self restoring. Supervisory latch
and require RESET to clear.
SCROLL DOWN / BUZZER SILENCE:
Acknowledge troubles and supervisory.
Once all events in trouble or supervisory state have been
viewed, the panel buzzer and appropriate output will
silence. The applicable TROUBLE or SUPERVISORY
LED will change from flashing to steady.
A Second trouble or supervisory will resound the panel
buzzer.
Trouble conditions are self restoring. Supervisory latch
and require RESET to clear.
SIGNAL SILENCE:
By pressing SIGNAL SILENCE button, all silencable
outputs will de-activate. A trouble condition will be
created, TROUBLE contact will be activated and the
yellow ALARM SILENCE LED will light.
WARNING ! Alarms initiated from a WATERFLOW
signal can not be silenced. The panel must be reset
to silence audible devices.
