FireFlex TOTALPAC2 - Deluge System with Electric Release

TOTALPAC2 Page 11 of 12
TOTALPAC2 Integrated Fire Protection Systems
Mechanical Section - Deluge System
FM-086G-0-24D
4- Deluge System with Electric Release
1. Description
The T
OTALPAC2 System with the Viking Deluge Trim utilizes
a Viking Deluge valve (A1) to control water flow into system
piping equipped with open sprinklers and/or spray nozzles.
The system piping remains empty until the Deluge Valve is
activated by operation of the release system.
Electrically controlled deluge systems require an electric
Solenoid valve (F1) controlled by an approved System
Control Panel with compatible detection system. In fire
conditions, when the detection system operates, System
Control Panel energizes the Solenoid Valve (F1) open,
causing Deluge Valve (A1) to open and allowing water to
enter the system piping. Water will flow from any open
sprinklers and/or spray nozzles on the system.
Deluge systems are designed so the Deluge valve will
open when a detector on the electric release system
operates. When the Deluge Valve opens, water will flow
into the sprinkler piping and out of any open sprinklers,
open spray nozzles and any opening on the system.
Deluge T
OTALPAC2 Systems are commonly used where it is
desirable to simultaneously spray water from all open
sprinklers and/or spray nozzles on the system when the
system operates.
2. Normal condition
1. Control panel
of the TOTALPAC2 system
a) Green lamp identified "AC POWER" lights up.
b) All other lamps are off.
2. Valves
a) Main water supply control valve (D1) is OPEN.
b) All upstream water supply valves are OPEN.
c) Priming valve (B1) is OPEN.
d) Flow test valve (B6) is CLOSED.
e) System main drain valve (D3) is CLOSED.
f) Alarm test valve (B5) is CLOSED
g) Manual emergency release valve (B10) is CLOSED
(handle in vertical position).
h) All gauge valves are OPEN.
3. Gauges
a) Water supply (B12) - at water supply pressure
b) Priming chamber (B11) - should be equal to, or
higher than, water supply pressure (B12).
4. Pressure switch
a) Alarm switch (C1) - should activate when pressurized
higher than 5 psi.
5. Optional equipment (see OPTIONAL EQUIPMENT
SECTION)
a) Shut-off valve (D4) is OPEN.
REFER TO TRIM SCHEMATIC ON NEXT PAGE.
