2 Integrated Fire Protection System
System design & Dimensional Data
FM-086G-0-48C
1- Skid mounted Unit
The T
OTAL
P
AC
2 unit skid is made of sturdy 14 gauge steel,
measuring 36" x 20" x 6" (91,4 x 50,8 x 15,2 cm) for 1½", 2"
& 3" systems and 46" x 24" x 6" (116,8 x 61 x 15,2 cm) for 4"
& 6" systems (refer to Figures 1 to 5 for dimensions).
All surfaces are rust proof coated, inside and outside, with
fire red, oven baked polyester powder on phosphate base.
IMPORTANT! The T
OTAL
P
AC
2 skid units are NOT designed
to be installed where they will be subjected to outdoors
and/or freezing conditions. Refer to environmental data for
additional details. Subjecting the unit to conditions outside
these limitations might hamper the normal operation of the
system.
The skid assembly is pre-assembled and factory tested
under ISO-9001 conditions (refer to following figures for
installation and clearances details).
Note: This skid unit contains only the mechanical section of
the T
OTAL
P
AC
2 trim. Electrical connections, control panel
and air supply when applicable are provided by others.
Multiple unit installations are easily achieved by manifolding
units together at their water inlets but drains shall remain
separate and open. Refer to Figure 4 & 5 for additional
details on how to pipe the drains.
Shipping weights
System Size
(Dia.)
Lbs. Kg.
PREACTION
1½" 285 192
2" 310 141
3" 440 200
4" 510 231
6" 710 322
Note: Above Shipping Weights are nominal and will change
depending on configuration and options selected.
