TOTALPAC2 Integrated Fire Protection System
Control Section
FM-086G-0-29C
2- Control Section without control panel.
2.1 Product Description
When the T
OTALPAC2 unit is provided without any control
panel, such as in retrofit applications where the unit is
connected and controlled by a central control panel
already installed in the building or premises.
When such is the case, the top control section of the
T
OTALPAC2 is not provided and is replaced by a field
wiring junction box (See Figure 1 for details). All electrical
components in the trim (pressure switches, supervisory
switches, etc.) are factory wired to a terminal strip (TBA)
for contractor's field wiring. The junction box is provided
with a cover plate maintained in place by 4 screws and
contains the wiring schematic on it's internal face.
Junction box has 4 knock-outs for contractor field wiring.
2.2 Remote Controlled T
OTALPAC2 (without Control
Panel)
The installing contractor should make sure the remote
control panel is both listed and programmed to handle the
required sequence of operation necessary to operate the
automatic sprinkler system. Refer to GENERAL
DESCRIPTION Section, appropriate standards and
Authority Having Jurisdiction for additional information.
2.3 Technical Data
Cabinet:
Steel enclosure: Refer to Cabinet Data Sheet for further
details.
Environment (electrical section):
Temperature: 32
o
F. (0
o
C) to 120
o
F (48
o
C)
Humidity: 85% Relative Humidity (non-condensing) at
90
o
F (32
o
C) maximum.
AC Power:
The unit may be provided with an air compressor . Refer to
the appropriate Field Wiring Diagram in "Programming
Section" to determine applicable power requirements.
Wire size: minimum #14 AWG with 600 Volt insulation.
Note: This T
OTALPAC2 Unit has been provided without an
Integrated Control Panel, which is supplied by others.
Contractor should make sure the control panel supplied to
control this system complies with the sequence of
operation described in the programming Section. The
remote control panel shall also be listed for releasing
service and be compatible for supervising N.O. contact
devices and operating the 24 Vdc/10Wdc solenoid valve of
the system if applicable.
