FireFlex TOTALPAC2 - Cabinet for Self-Contained Unit

T OTAL P AC 2 Page 9 of 12
T OTAL P AC 2 Integrated Fire Protection System
System design & Dimensional Data
FM-086G-0-48C
3- Cabinet for Self-Contained Unit
The T OTAL P AC 2 unit cabinet is made of sturdy 14 gauge
steel, measuring 36" x 20" x 71" (91,4 x 50,8 x 180,3 cm) for
1½", 2" & 3" systems and 46" x 24" x 71" (116,8 x 61 x 180,3
cm) for 4" & 6" systems (refer to Figure 1 for dimensions).
All surfaces are rust proof coated, inside and outside, with
fire red, oven baked polyester powder on phosphate base.
Cabinet is provided with individual access doors for the
hydraulic and electrical sections and the emergency release
with a neoprene gasket to avoid vibrations.
Electrical junction boxes are integrated with the cabinet for
connection of detection system, auxiliary contacts and
signaling devices. Knockouts can be drilled by the installing
contractor on-site but have to meet the restrictions indicated
on Figure 3.
Gauges to indicate air, water supply pressure and priming
water pressure are all visible through clear Lexan windows.
IMPORTANT! T OTAL P AC 2 units are NOT designed to be
installed where they will be subjected to outdoors and/or
freezing conditions. Refer to ENVIRONMENTAL DATA for
additional details. Subjecting the unit to conditions outside
these limitations might hamper the normal operation of the
system.
Cabinet doors are provided with hinges that can easily be
disassembled on site to remove the door assemblies for
servicing. The cabinet assembly is pre-assembled, pre-
wired, and factory tested under ISO-9001 conditions. Refer
to Figure 2 for installation and clearances details.
Note: The mechanical section of the T OTAL P AC 2 and the
electrical section are provided in two separate enclosures,
stacked one on top of the other. The cabinet is Listed both
with or without the control panel section.
Multiple unit installations are easily achieved by manifolding
units together at their water inlets but drains shall remain
separate and open. Refer to Figure 7 for additional details
on how to pipe drains.
Shipping weights:
System Size (Dia.)
Lbs. Kg.
PREACTION
1½" 610 277
2" 635 288
3" 770 349
4" 856 388
6" 1071 486
Note: Above Shipping Weights are nominal and will change
depending on configuration and options selected.
