Page 2 of 12
T
OTAL
P
AC
2
T
OTAL
P
AC
2 Integrated Fire Protection System
System design & Dimensional Data
FM-086G-0-48C
Figure 1 – Dimensions - Preaction:
System
Size
A B C D E F G H J K L M N P Q R S T
1½"
2" 1½" 2" 36" 46" 20" 4" 8
" 9" 18½"
3½" 6" 2" 34½"
5" 19½"
41¾"
13¾"
2"
2" 2" 2" 36" 46" 20" 4" 8
" 9" 18½"
3½" 6" 2" 34" 5" 19½"
41¼"
14½"
3"
4" 3" 2" 36" 46" 20" 4" 9
" 9" 18½"
3½" 6" 2" 38⅜"
5" 19½"
42⅛"
14½"
4"
4" 4" 2" 46" 46" 24" 4" 9
" 10" 18½"
3½" 6" 2" 39⅝"
6½" 19½"
44¼"
16⅞"
6"
6" 6" 2" 46" 46" 24" 4" 11" 10" 18½"
3½" 6" 2" 48⅝"
6½" 19½"
54½"
21"
Note: Some dimensions and actual skid layout may vary depending on options and configuration selected.
