TOTALPAC2 Page 9 of 12
TOTALPAC2 Integrated Fire Protection Systems
Mechanical Section - Deluge System
FM-086G-0-24D
3- System with Pneumatic Release
1. Description
The T
OTALPAC2 System with the Viking Deluge Trim utilizes
a Viking Deluge valve (A1) to control water flow into system
piping equipped with open sprinklers and/or spray nozzles.
The system piping remains empty until the Deluge Valve is
activated by operation of the release system.
Pneumatically controlled deluge systems require a pneumatic
release system, equipped with fixed temperature releases
and/or pilot heads. Release trim, for pneumatically controlled
deluge systems utilize a Pneumatic Actuator (F3) normally
held closed by pressure maintained in the pneumatic release
system.
Deluge systems are designed so the Deluge valve will
open when a detector on the pneumatic release system
operates. When the Deluge Valve opens, water will flow
into the sprinkler piping and out of sprinklers and any
opening on the system.
Note: The air supply for the pneumatic release piping
system must be provided by the contractor and installed
outside the TOTALPAC2 cabinet. The air supply must be
restricted to ensure that the automatic air supply cannot
replace air as fast as it escapes when a releasing device
operates. It is also recommended to provide Inspectors
Test Connections on both the release system and the
sprinkler system.
Deluge T
OTALPAC2 Systems are commonly used where it is
desirable to simultaneously spray water from all open
sprinklers and/or spray nozzles on the system when the
system operates.
2. Normal condition
1. Valves
a) Main water supply control valve (D1) is OPEN.
b) All upstream water supply valves are OPEN.
c) Priming valve (B1) is OPEN.
d) Flow test valve (B6) is CLOSED.
e) System main drain valve (D3) is CLOSED.
f) Alarm test valve (B5) is CLOSED
g) Manual emergency release valve (B10) is CLOSED
(handle in vertical position).
h) All gauge valves are OPEN.
2. Gauges
a) Water supply (B12) - at water supply pressure
b) Priming chamber (B11) - should be equal to, or
higher than, water supply pressure (B12).
c) Release system air pressure (E3) and Pneumatic
Actuator (F4) – See table 1 below.
3. Pressure switch
a) Alarm switch (C1) - should activate when pressurized
higher than 5 psi (35 kPa).
b) Release system low air pressure switch (E4) – See
Table 1 below.
4. Optional equipment (see OPTIONAL EQUIPMENT
SECTION)
a) Shut-off valve (D4) is OPEN.
Table 1: Pressure Settings
WATER SUPPLY PRESSURES
DEVICE
Up to 175 psi
(1 207 kPa)
175 psi (1 207 kPa)
to 250 psi (1724 kPa)
Release System Air
Pressure Gauge (E3)
35 PSI (241 kPa) 55 PSI (380 kPa)
Pneumatic Actuator
Pressure Gauge (F4)
35 PSI (241 kPa) 55 PSI (380 kPa)
Low Air Supervisory
Pressure Switch (E4)
25 PSI (173 kPa) 45 PSI (311 kPa)
REFER TO TRIM SCHEMATIC ON NEXT PAGE.
