TOTALPAC2 Page 5 of 12
TOTALPAC2 Integrated Fire Protection System
Deluge System - Programming & Field Wiring Diagram
FM-086G-0-38E
3- Remote Controlled, Electric Release
The TOTALPAC2 Unit without control panel is factory wired for
the following configuration:
f System with Electric Release
This T
OTALPAC2 Unit has been provided without an
Integrated Control Panel since its dry contacts are
supervised by a remote panel. Contractor should make sure
the control panel supplied to control this system complies
with the sequence of operation described in MECHANICAL
TRIM SCHEMATIC. The remote control panel shall also be
Listed and be compatible for supervising sprinklers
supervisory and alarm contact devices and be compatible for
supervising N.C. 24Vdc Solenoid Valve.
Refer to FIELD WIRING DIAGRAM for more details. Make
sure the system will perform as required and is tested to
confirm it meets all requirements.
Note: All field wiring should be terminated in the contractor
junction box and terminals provided (TBA and TBB) as
shown on the FIELD WIRING DIAGRAM. No connection
should be made directly in the trim components as this
would void warranty and might prevent the normal
operation of the unit.
Operation – Deluge
When the detection system operates, the System Control
Panel activates an alarm and energizes the normally closed
solenoid valve (F1) open. Pressure is released from the
priming chamber faster than it is supplied through restricted
orifice (B3). The deluge valve clapper opens to allow water to
flow into the system piping and alarm devices, causing the
water motor alarm and water flow alarms connected to the
alarm pressure switch to activate. Water will flow from any
open sprinklers and/or spray nozzles on the system.
1. System Manual Operation
Manual opening of the deluge valve by the operation of
the manual emergency release valve causes the water
flow switch to operate.
Note: The same sequence is obtained with the operation
of the alarm test valve, but the deluge valve is kept
closed.
2. Supervisory of the Valves
An abnormal position of a valve will cause the closing of
the Valve Supervisory Switch contact. Both the Water
Supply Control Valve and the optional Shut-off Valve are
supervised.
