FireFlex TOTALPAC2 - Page 34

Page 10 of 14 T OTAL P AC 2
T OTAL P AC 2 Integrated Fire Protection System
Air Supply
FM-086G-0-43E
Table 2: Water Pressure from 175 Psi to 250 Psi
System Type
Air Supply
Style
Air
Regulator
Compressor
Start
Compressor
Stop
Low Air
Supervisory
Low Air
Alarm
A n/a
50 Psi
(345 kPa)
55 Psi
(380 kPa)
45 Psi
(311 kPa)
n/a
Non-Interlocked
Pneumatic Release
B or D
50 Psi
(345 kPa)
n/a n/a
45 Psi
(311 kPa)
n/a
A n/a
50 Psi
(345 kPa)
55 Psi
(380 kPa)
45 Psi
(311 kPa)
43 Psi
(NYC) Non-Interlocked
Electric Release
B or D
50 Psi
(345 kPa)
n/a n/a
45 Psi
(311 kPa)
43 Psi
(NYC)
A n/a
50 Psi
(345 kPa)
55 Psi
(380 kPa)
45 Psi
(311 kPa)
n/a
Single-Interlocked
Pneumatic Release
B or D
50 Psi
(345 kPa)
n/a n/a
45 Psi
(311 kPa)
n/a
A n/a
15 Psi
(104 kPa)
20 Psi
(138 kPa)
12 Psi
(83 kPa)
10 Psi
(NYC) Single-Interlocked
Electric Release
B or D
20 Psi
(138 kPa)
n/a n/a
12 Psi
(83 kPa)
10 Psi
(NYC)
A n/a
50 Psi
(345 kPa)
55 Psi
(380 kPa)
45 Psi
(311 kPa)
n/a
Double-Interlocked
Pneumatic/Pneumatic
B or D
50 Psi
(345 kPa)
n/a n/a
45 Psi
(311 kPa)
n/a
A n/a
15 Psi
(104 kPa)
20 Psi
(138 kPa)
12 Psi
(83 kPa)
10 Psi
(69 kPa)
Double-Interlocked
Electric/PneuLectric
B or D
20 Psi
(138 kPa)
n/a n/a
12 Psi
(83 kPa)
10 Psi
(69 kPa)
A n/a
50 Psi
(345 kPa)
55 Psi
(380 kPa)
45 Psi
(311 kPa)
43 Psi
(NYC) Double-Interlocked
Electric/Pneumatic
B or D
50 Psi
(345 kPa)
n/a n/a
45 Psi
(311 kPa)
43 Psi
(NYC)
A n/a
50 Psi
(345 kPa)
55 Psi
(380 kPa)
45 Psi
(311 kPa)
43 Psi
(297 kPa) Single-Interlocked
Firecycle III
B or D
50 Psi
(345 kPa)
n/a n/a
45 Psi
(311 kPa)
43 Psi
(297 kPa)
A n/a
50 Psi
(345 kPa)
55 Psi
(380 kPa)
45 Psi
(311 kPa)
43 Psi
(297 kPa) Double-Interlocked
Firecycle III
B or D
50 Psi
(345 kPa)
n/a n/a
45 Psi
(311 kPa)
43 Psi
(297 kPa)
A n/a
50 Psi
(345 kPa)
55 Psi
(380 kPa)
45 Psi
(311 kPa)
43 Psi
(297 kPa) Single-Interlocked
SUREFIRE
B or D
50 Psi
(345 kPa)
n/a n/a
45 Psi
(311 kPa)
43 Psi
(297 kPa)
A n/a
50 Psi
(345 kPa)
55 Psi
(380 kPa)
45 Psi
(311 kPa)
43 Psi
(297 kPa)
Double-Interlocked
SUREFIRE
B or D
50 Psi
(345 kPa)
n/a n/a
45 Psi
(311 kPa)
43 Psi
(297 kPa)
Release (pilot) Line C
50 Psi
(345 kPa)
n/a n/a
45 Psi
(311 kPa)
n/a
A n/a
50 Psi
(345 kPa)
55 Psi
(380 kPa)
45 Psi
(311 kPa)
n/a
Dry Pipe System
B or D
50 Psi
(345 kPa)
n/a n/a
45 Psi
(311 kPa)
n/a
