General operation
Seite/Page 12 - Kapitel/Chapter 3: General operation 20.10.22
Display screen for 3-phase generators
Fig. 3.3.3.4-4: Inverter screen in operation mode (3-phase)With the 3-phase i-series generators, there is an additional
screen in operation mode for the inverter data. This screen
provides the latest inverter output voltage of the single
phases with the matching conductor current and the circuit
board temperature. The inverter will be switched off at a
circuit board temperature of 75 °C.
You can access the inverter screen by actuating the cursor-
down button while in operation mode.
3.3.3.5 Panda i-Generator with electro-magnet Clutch (optional)
Attention!During the activation of the electro-magnetic clutch, the
iControl3 raise the generator speed to maximum.
After the clutch is released, the generator speed will drop to
normal.
