Installation
20.10.22 Kapitel/Chapter 4: Installation - Seite/Page 29
4.2.2.4 Function of the double DIP Switch
The terminating resistors for CAN bus 1 and CAN bus 2 are switched on and off with the double DIP switch.
Note! Notice the information on the operation of master and
slave panels. See “Master and Slave Panels” on page 34.
Fig. 4.2.2.4-1: Positions of the double DIP switch
Switch Function Switch position
1 Terminating resistor for CAN bus 1 On/Off top - terminating resistor “ON”, down - terminating resistor “OFF”
2 Terminating resistor for CAN bus 2 On/Off
