Fischer Panda iControl3 User Manual

Annex
20.10.22 Kapitel/Chapter 7: Annex - Seite/Page 45
7. Annex
7.1 Technical data
7.1.1 Technical data for iControl3 control unit
Fig. 7.1.1-1: Technical data for iControl 3 control unit
7.1.2 Technical data for iControl3 remote control panel
Fig. 7.1.2-1: Technical data for iControl3 remote control panel
iControl3 control unit
Supply voltage 12 V-13,5 V (12 V automotive)
Current consumption, nominal 80 mA @14,4 V
Current consumption, stand-by < 0,1 mA
Operating temperature -20 °C to +105 °C
Storage temperature -30 °C to +125 °C
Housing Automotive, PBT GF30
Protection class IP65
Overall dimensions 134,2 x 118,7 x 36,3 mm (L x W x H including connector)
Connector 42-pin connector
Weight 0,25 kg
FP part number 0034981
iControl3 control unit
Supply voltage 12 V-24 V (12 V or 24 V automotive)
Current consumption, off 0 mA
Current consumption, stand-by - backlight brightness 90 % 60 mA
Current consumption, stand-by - backlight brightness 40 % 50 mA
Current consumption, stand-by - backlight brightness 0 % 40 mA
Operating temperature -20 °C to +70 °C
Storage temperature -30 °C to +80 °C
Housing ABS plastic
Protection class IP04
Overall dimensions 120 x 65 x35 mm (L x W x H), Cutout: 109,2 x 54,5 mm
FP part number 0034806

Fischer Panda iControl3 Specifications

General

Brand	Fischer Panda
Model	iControl3
Category	Controller
Language	English
