Fischer Panda iControl3 User Manual

General operation
20.10.22 Kapitel/Chapter 3: General operation - Seite/Page 15
3.4.1 Submenu »Panel«
Fig. 3.4.1-1: Set-up menu, highlighted *Panel*Calling up the submenu »Panel«:
• Select *Panel* and confirm with the start/stop button.
Fig. 3.4.1-2: Submenu »Panel« highlighted *Backlight 1*With the cursor-up and cursor-down buttons, you can
navigate through the menu. The currently selected menu
item is marked with two asterisks (*), e. g. *Backlight 1*.
Fig. 3.4.1-3: Submenu »Panel«, highlighted *Back*Set-up submenu »Panel« with item highlighted: *Back*
Note!The start/stop button is used to confirm the selected item in
the set-up menu. Confirming the row marked with the *
accesses the selected submenu.
Fig. 3.4.1-4: Items of the submenu »Panel«
3.4.1.1 Setting the backlight (»Backlight« and »Dimtime«)
The brightness of the display backlight of the Panda iControl3 panel can be varied from 0 to 100 % in 1 % steps.
Also, the display can be dimmed with a timer if no button is actuated on the control panel for a parameter is able
Menu item Settings range for
Backlight 1 Setting the brightness value for the standard backlighting to 0-100 %
Backlight 2 Setting the brightness value for the dimmed backlighting to 0
-100 %
Dimtime (dimming time) Time until the display switches to dimmed mode, 0-255 s (corresponds to 0-4 min), 0= lighting is always dimmed
Language Language selection (English, German and French available)
Units Switches the display between °C and °F
Network Settings for the network ID of the panel
Back Exiting the set-up submenu »Panel«
