Installation
Seite/Page 32 - Kapitel/Chapter 4: Installation 20.10.22
4.4.1 Terminal assignment of the 42-pin socket
Fig. 4.4.1-1: Terminal assignment of the 42-pin socket
Terminal IN / OUT Function
1 OUT Glow plug(s)
2 IN Spare input
3 -- not used
4 -- Supply voltage Inverter
5 -- not used
6 OUT Water pump
7 OUT Booster (optional, depending on generator type)
8 -- not used
9 -- GND
10 -- CAN high 2
11 -- VCCS +5V servo motor (red wire)
12 -- GND
13 -- GND
14 -- Supply voltage+
15 OUT Electric starter
16 IN Spare input
17 IN Cylinder head temperature
18 IN Exhaust manifold temperature
19 IN Oil pressure switch
20 IN Universal input
21 IN Emergency stop+
22 -- CAN high 1
23 -- CAN low 2
24 -- Bus supply voltage
25 -- GND servo motor (black wire))
26 OUT Potential-free output (PWM-)
27 IN Pick-up sensor
28 -- Supply voltage+
29 OUT Fuel pump
30 IN Spare input
31 IN Spare input
32 IN Winding temperature
33 -- GND
34 -- GND
35 IN Emergency stop-
36 -- CAN low 1
37 IN Wake up
38 -- GND
39 -- PWM servo motor (yellow wire)
40 OUT Potential-free output (PWM+)
41 -- not used
42 -- GND
