Warnings and error messages
20.10.22 Kapitel/Chapter 6: Warnings and error messages - Seite/Page 41
6.2.1 Error messages
All error messages defined for the Panda iControl3 and the corresponding display texts are compiled in the
subsequent table.
Fig. 6.2.1-1: Error messages
Fig. 6.2.1-2: Error codes
Error message on the display Meaning of error message
„Error“ is output instead of a temperature Broken cable on corresponding temperature sensor
Error
code
Meaning Error Message English Error Message German
1 Inverter voltage low L1 L1 undervoltage L1 Unterspannung
2 AC frequency low L1 L1 low frequency L1 Frequenz niedrig
5 Emergency stop Emergency stop Nothalt
7 Oil pressure fault FAULT: OILPRESS Fehler: Öldruck
8 Engine temperature out of range OUT: Cyl. head OUT: Motor
9 Winding temperature out of range OUT: Winding OUT: Wicklung
10 Exhaust temperature out of range OUT: Exhaust OUT: Abgas
25 Starter battery voltage low Battery voltage low Batt. Unterspannung
26 Starting fails Starting fails Startfehler
28 unexpected stop (revolution speed low) UNEXPEXTED STOP Unerwarteter stopp
30 Inverter voltage low L2 L2 undervoltage L2 Unterspannung
31 AC frequency low L2 L2 low frequency L2 Frequenz niedrig
34 Inverter voltage low L3 L3 undervoltage L3 Unterspannung
35 AC frequency low L3 L3 low frequency L3 Frequenz niedrig
65 Inverter voltage high L1 L1 Overvoltage L1 Ueberspannung
66 AC frequency L1 high L1 frequency high L1 Frequenz hoch
67 Inverter overload L1 L1 Overload L1 Ueberlast
70 Servo current high Servo current high Servo Ueberstrom
72 Engine temperature fault Temp: cyl. head Temp. Motor
73 Winding temperature fault Temp: winding Temp. Wicklung
74 Exhaust temperature fault Temp: exhaust Temp. Abgas
75 Electronic temperature high ECU temp. high ECU Temperatur hoch
77 Starter output high Starter overcurrent Anlasser Ueberstrom
78 Glow plugs output high Glowplug overcurrent Gluehkerze Ueberstrom
79 Flame plug output high Flameplug overcurrent Flammkerze Ueberstrom
80 Fuel supply output high Fuelpump overload Kraftstoffpumpe Ueberstrom
81 ETR-Hold current high ETR-hold overload ETR-hold Ueberstrom
82 ETR-Pull current high ETR-pull overload ETR-pull Ueberstrom
83 Fan output high Fan overcurrent Luefter Ueberstrom
85 Boost relay high Boost overcurrent Boost Ueberstrom
86 Bus current high Bus overcurrent Bus Ueberstrom
89 Starter battery voltage high Battery voltage high Batt. Ueberspannung
90 Engine revolution (RPM) high Overspeed Ueberdrehzahl
94 Inverter voltage high L2 L2 Overvoltage L2 Ueberspannung
93 Power contactor Inv. switch overload Inv. Schalter Ueberlast
95 AC frequency L2 high L2 frequency high L2 Frequenz hoch
96 Inverter overload L2 L2 Overload L2 Ueberlast
98 Inverter voltage high L3 L3 Overvoltage L3 Ueberspannung
99 AC frequency L3 high L3 frequency high L3 Frequenz hoch
