FJDZ42P Electric Zero-turn Mower User Manual
Figure 5. Settings screen of the control terminal
No.
Name
Function
1
Settings menu
Includes settings and real-time status.
2
Exit button
Tap to return to the home screen.
5.4 Lap Bars
Figure 6. Left and right lap bars and structure
Use the left and right lap bars to control the driving speed and direction, stop the mower, and apply
the parking brake.
The mower will not move, when the two lap bars are in the parking position.
No.
Name
1
Upper lever
