5.8 Anti-scalp Wheel
Anti-scalp wheel comes standard on the FJD mower. They are designed to minimize scalping when
mowing on rough and uneven terrain. After the cutting height is set, adjust the anti-scalp wheels so
they extend below the deck but do not touch the ground. Always keep the anti-scalp wheels 20 mm
(0.78 inches) below the blades. The anti-scalp wheels can be adjusted upward or downward as
needed in the range of 20–70 mm (0.78–2.75 inches) below the blades after parking the mower on a
level surface.
Figure 9. Anti-scalp wheels and axle mount holes
Move the wheels upward or downward by using the different axle mount holes in the wheel mount
bracket.
5.9 Manual Release of Electromagnetic Brakes
When a power failure occurs or the battery pack is depleted, you can release the electromagnetic
brakes of drive motors manually so that you can push the mower out of the operation area. While
the mower is running, ensure that the electromagnetic brakes are functional.
