FJDynamics FJDZ42P - Wheels

- 59 -
©2022 FJDynamics. All rights reserved.
FJDZ42P Electric Zero-turn Mower User Manual
Standard tire pressure
Tire
Specifications
Pressure
Front
10 × 4–6 inches
42 PSI
Rear
20 × 8–10 inches
22 PSI
Note: Inspect the tires on a daily basis and replace the damaged tires immediately.
WARNING
Do not use the mower when the wheel and axle bolts are loose. Ensure that the bolts are
tightened.
9.2.2 Wheels
Tighten the bolt  with a torque of 80–90 N·m after replacing the wheel, drive the mower for
about 200 m, and then check the torque again.
Figure 34. Rear wheel bolt
Bolt torque: 80–90 N·m (59–66 lb-ft)
Removing the Front Wheel
1. Park the mower on a flat ground.
2. Place the lap bars in the parking position, press the start/stop button and press the emergency
stop button to power off the mower.
