- 60 -
©2022 FJDynamics. All rights reserved.
FJDZ42P Electric Zero-turn Mower User Manual
3. Lift the forepart of the mower properly with dedicated tools.
4. Remove the locknut  and pull out the front wheel bolt .
5. Remove the front wheel from the yoke .
Figure 35. Remove the front wheel
No.
Name
1
Locknut
2
Front wheel bolt
3
Yoke
Installing the Front Wheel
1. Place the front wheel in the correct position.
2. Insert the front wheel bolt  and mount the locknut .
3. Tighten the locknut with the required torque.
Tightening torque of the front wheel: 80–90 N·m (59–66 lb-ft)
NOTICE
Insert the front wheel bolt from the external side of the yoke. Gradually tighten the locknut
until there is no gap between it and the front wheel bearing and the front wheel can be turned
by hand.
