4. Connect the wire terminal of the blade motor to the drive wire terminal.
5. Adjust the levelness and height of the cutting deck, and tighten the fasteners to complete
installation.
7.8.2 Adjusting the Levelness and Height of the Cutting Deck
After installing the cutting deck, check its levelness and height. If necessary, adjust the levelness
and height of the cutting deck. When the cutting deck is not parallel to the ground, adjust the
adjustment lever and the rear rod . Check the cutting deck height. When the cutting deck is in
the lowest position, ensure that the vertical distance between the blade tip and the ground is 30
mm (1.2 inches).
Note: Before checking the cutting deck height, ensure that the tire pressure is at the
specified level. If the tire pressure is abnormal, the deck cannot be adjusted to the correct
cutting height.
