FJDZ42P Electric Zero-turn Mower User Manual
Figure 27. Slide the cutting deck under the mower chassis
2. Connect the rear bracket  of the cutting deck to the linkage rod  with the clevis pin  and
the cotter pin .
Figure 28. Rear connection of the cutting deck
No.
Name
1
Linkage rod (on both sides)
2
Rear cutting deck bracket (on both sides)
3
Clevis pin (on both sides)
4
Cotter pin (on both sides)
3. Raise the cutting deck, and attach the adjustment lever  to the front bracket  of the cutting
deck.
