FJDZ42P Electric Zero-turn Mower User Manual
No.
Name
1
Bolt
2
Wooden block
3
Blade holder
When mounting a new blade, make its edge face the ground.
Place the disc spring  between the blade  and the bolt , as shown in the figure below.
Tighten the bolt  with a torque of 160–200 N·m (118–147 lb-ft).
Figure 40. Mount a mower blade
No.
Name
1
Bolt
2
Disc spring
3
Blade
4
Blade holder
9.4.3 Torque
WARNING
Tighten the wheel bolts and the blade bolts, otherwise, the wheels or blades may be lost,
resulting in serious machine damage or personal injury.
The torque values are as follows:
