FJDynamics FJDZ42P - Filling the Lubricating Grease; Drive Axle Reducer Oil Maintenance

- 61 -
©2022 FJDynamics. All rights reserved.
FJDZ42P Electric Zero-turn Mower User Manual
9.2.3 Filling the Lubricating Grease
Inject the lubricating grease into the grease nipple .
Figure 36. Fill the lubricating grease
No.
Name
1
Grease nipple (on both sides)
9.3 Drive Axle Reducer Oil Maintenance
Recommended oil maintenance period: 500 h or 6000 km; oil: SAE85W-140; oil capacity: 400 ± 20
ml.
1. Unscrew the drain plug  to drain the oil.
2. Tighten the drain plug with a torque of 5–7 N·m.
3. Unscrew the oil cap  and fill oil.
4. Tighten the oil cap with a torque of 3–5 N·m.
