M3560-02en Edition 09/2022 25
Assembly
5
Assembly of the coupling comprises the following steps:
• Preparatory work (Page25)
• Mounting the coupling (Page30)
• Aligning the coupling (Page33)
• Fill with lubricant (Page36)
DANGER
Danger due to bursting of the coupling
If you do not observe the information stipulated here regarding assembly, this can lead to
bursting of the coupling during operation. There is a risk of fatal injury from flying frag-
ments. If a coupling bursts in an area at risk of explosion, then this can result in an explo-
sion.
• Carefully observe all of the specifications relating to assembly.
Notes regarding assembly of the coupling
• Only use undamaged components when assembling the coupling.
• Follow the assembly sequence.
• Please ensure that there is sufficient space at the assembly location and that the loca-
tion is tidy and clean in order to be able to assemble and maintain the coupling without
any risk.
• If a dimension drawing has been created for the coupling, please observe the informa-
tion it contains as a matter of priority.
5.1 Preparatory work5.1 Preparatory work
Please consult Flender if you want to machine a conical finished bore.
Carry out the following steps if the coupling does not have a finished bore:
• Mill the finished bore (Page26)
• Mill the parallel keyway (Page27)
• Machining an axial locking mechanism (Page27)
• Balancing the coupling (Page30)
Information
The customer is responsible for execution of the finishing work on the coupling. Flender
shall have no liability whatsoever for claims under warranty arising from finishing work that
has not been carried out adequately.
