FLENDER ZAPEX - Dimension Drawing for ZNNV Types; Figure A-4 General ZNZA Illustration

Technical specifications
Speeds, geometry data and weights
M3560-02en Edition 09/2022 63
"
4
"
FigureA-4:General ZNZA illustration
A.1.3 Dimension drawing for ZNNV types Speeds, geometry data and weights
For clearance S11 and S12, refer to Chapter Clearance S (Page66).
